Warehouse lifts

There are more than a hundred mast-type devices for various fields of activity in the enterprise catalog. The price for a particular warehouse elevator model depends on the design changes, the height of the mast and additional equipment.

Mast lifts, along with scissor lifts, are used in shops, shopping and warehouse complexes, restaurants and manufacturing enterprises.

The STROS company offers mast lifts for warehouses. Cargo for production or goods are moved on a platform with a mesh fence on the sides or in an open-top cab. The movement takes place along a vertical support mast, assembled from separate welded sections.

Types of lifting mechanisms:

  • Pinion gear on cab or platform, joining to rack on mast
  • Winch with rope

Cargo lifts for the warehouse elevators are installed inside the building or outside, a fence may be provided around. The equipment is driven by an electric drive, which is connected to the network with a suspension cable. In order to protect against wind swinging, the cable is fixed with guides.

Warehouse lifts

ALULIFT 200 S

Platform Hoist

Max. height: 19 m
Max. weight: 200 kg
Speed: 25 m/min
FIND OUT MORE

ALULIFT 200 V

Platform Hoist

Max. height: 60 m
Max. weight: 200 kg
Speed: 25 m/min
FIND OUT MORE

NV 2038 F4

Material Hoist

Max. height: 350 m
Max. weight: 2000 kg
Speed: 20 m/min
FIND OUT MORE

Specifications

Characteristics ALULIFT 200 S ALULIFT 200 V NV 2038 F4
Delivery height max. 19 m to cornice max. 60 m 350 m
Load capacity 200 kg 200 kg 2000 kg
Lifting speed 25 m/min 25 m/min 40 m/min
Masts — — S
Internal dimensions of the lift — — 1390 x 3800 mm
Supply system 1 NPE 50 Hz 230V 1 NPE 50 Hz 230V —
Drive motor power 1,5kW 1,5kW 2 x 9,2kW / 2 x 12HP
Informations — — operated from base station, only for material transport
Control voltage 24В AC 24В AC —
Rated current [400V / 480V] — — 68A / 57A
Starting current [400V / 480V] — — 102A / 85,5A
Main protection [400V / 480V] — — 90A / 80A
Recommended fuse protection [400V / 480V] — — 100A / 100A
Warehouse lifts from the manufacturer

ALULIFT series. The lifting devices are made of aluminum, the mast recalls a ladder. The platform is lifted by a winch with a cable, the lifting height changes over 2 meters to the maximum value. The equipment is easy to assemble, plugs into a standard 230 V socket.

NV series. The lifts have a floor programming function. The lifting mechanism is a gear with a rack, the equipment can also be equipped with a winch and cable. Cabin length is 3–3.8 meters. For safety, the lifts of the series are equipped with catchers. It's possible to have two cabins on one mast, a door for loading bulky materials, an overload protection device.

OUR ADVANTAGES

Flexible working conditions Individual approach to each client.
Search for solutions in non-standard situations
Professional installation We make professional installation of mast lifts
Delivery from warehouse We deliver the equipment you purchased to the facility
Availability of spare parts Main consumables and spare parts are in stock
Large equipment park Large, constantly updated range of equipment
Honest prices We offer a price without intermediary markups
Plant Scherer, Georgia, USA
Industrial elevator
Scope of work: installation and commissioning of the lift HS-2000-F4, maintenance
Object:
Lifting height:
23 meters
Horse Mesa Dam, Arizona, USA
Industrial elevator
Scope of work: installation and commissioning of the lift HS-1000-F4, maintenance
Object:
Lifting height:
50 meters
Sutton Power Plant, North Carolina, USA
Industrial elevator
Scope of work: installation and commissioning of the lift HS-1200-F4, maintenance
Object:
Lifting height:
23 meters

OBJECTS WE HELP TO BUILD

58th Street, NY, USA
Turkey, Istanbul 3rd Bosphorus Bridge
Madison Square Garden, NY, USA
Russia, Moscow Mercury City Tower
Russia, Moscow OKO, Complex
St. Petersburg, Russia
Russia, Krasnogorsk Crocus City, Project
Russia, St. Petersburg Lakhta Center, Project

Certificates and Documentation

ISO 9001
Lifting Equipment
Commercial License

Benefits of warehouse lifts

It's better than an elevator. Buying a lift for a warehouse is much more profitable than installing a freight elevator. The advantages of this solution are easier installation, cheaper maintenance, less power consumption.

Execution variability. The modular design of the cab allows modifications, improvements and choose unloading directions to meet customer needs. A cab of greater load capacity can be mounted on two masts for stability, and it is also possible to place two cabs on one mast.

Work from a normal electric network. Warehouse lifts do not have to be connected to a 400V high voltage supply. Some lifts are designed to be powered by a standard 230V power supply.

Reliability in operation. The mast structure is very stable, designed for a long service life in severe conditions. The manufacturer's warranty is valid for 1 year.

Comparative characteristics of the series*

Series

Feature

ALULIFT NV
Load capacity, kg 200 2000
Lifting height, m 60 350
Speed, m/min 25 40
* - the maximum value is indicated.

The mast sections are made of a round pipe with a diameter of 76 mm, ordinary or high-strength stainless steel. The surface of ordinary steel pipe is hot-dip galvanized for corrosion protection. The wall thickness of the pipe is 4-8 mm, the specific parameters depend on the height of the mast.

Load capacity:

  • Small - up to 200 kg
  • Large - up to 2000 kg

Cargo lifts for the warehouse elevators are installed inside the building or outside, a fence may be provided around. The equipment is driven by an electric drive, which is connected to the network with a suspension cable. In order to protect against wind swinging, the cable is fixed with guides.
